Key Specs
| Engine power | 40.3 kW 54 hp |
||
|---|---|---|---|
| Cargo box dimensions | 1143 x 305 x 1320 mm 45 x 12 x 52 in. |
||
| Cargo box capacity (weight) | 454 kg 1000 lb |
||
| Towing capacity | Up to 1814 kg 4000 lb |
||
| Front suspension | Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel | ||
| Rear suspension | Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel | ||
| Final drive | Park, high, low, neutral, reverse transaxle | ||
| Four wheel drive | Dash switch actuated four-wheel drive system | ||
| Fuel capacity | 42.4 L 11.2 U.S. gal. |
Engine
| Type | 4-cycle gas, electronic fuel injection (EFI) | ||
|---|---|---|---|
| Displacement | 812 cc | ||
| Power | 40.3 kW 54 hp |
||
| Cooling system | Liquid |
Drivetrain
| Transmission | Continuously Variable Transmission (CVT) with clutch enclosure | ||
|---|---|---|---|
| Final drive | Park, high, low, neutral, reverse transaxle | ||
| Four wheel drive | Dash switch actuated four-wheel drive system | ||
| Traction assist | Limited slip front differential, Positive locking, switch actuated rear differential lock | ||
| Descent control | Yes |
Suspension
| Front | Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel | ||
|---|---|---|---|
| Rear | Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel |
Brakes
| Type | Front/rear hydraulic disc with twin piston front calipers | ||
|---|---|---|---|
| Park brake | Park in-transmission, Optional factory-installed secondary foot operated with hand release |
Tires / Wheels
| Front | 27×9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on alloy wheels 27×9-R14 Predator Heavy-Duty all-terrain radials on alloy wheels |
||
|---|---|---|---|
| Rear | 27×11-R14 Maxxis Bighorn 2.0 extreme terrain radials on alloy wheels 27×11-R14 Predator Heavy-Duty all-terrain radials on alloy wheels |
Dimensions / Capacities
| Wheelbase | 2146 mm 84.5 in. |
||
|---|---|---|---|
| Weight | With fuel and fluids: 1138 kg 2509 lb |
||
| Length | 3356 mm 132 in. |
||
| Width | 1763 mm 69.4 in. |
||
| Height | With antenna: 2215 mm 87.2 in. Antenna removed: 2038 mm 80.2 in. |
||
| Tread centers | Front: 1341 mm 52.8 in. Rear: 1259 mm 49.6 in. |
||
| Ground clearance | 284 mm 11.2 in. |
||
| Fuel capacity | 42.4 L 11.2 U.S. gal. |
||
| Cargo box dimensions | 1143 x 305 x 1320 mm 45 x 12 x 52 in. |
||
| Cargo box capacity (weight) | 454 kg 1000 lb |
||
| Payload capacity | 407 kg 897 lb |
||
| Towing capacity | Up to 1814 kg 4000 lb |
||
| Hitch | Standard receiver: 5.1 cm 2 in. |
Features
| Color | Green and yellow | ||
|---|---|---|---|
| Power steering | Yes | ||
| Battery / Alternator / Power port | Battery: 12 V 480 CCA Alternator: 85 amp DC outlet: 12 V |
||
| Instrumentation | Digital display (gear position, system diagnostic light, speed, rpm, 4WD indicator, rear differential indicator, fuel level, coolant temperature, hour meter, miles, and service interval warning light) 16.3 cm (6.4-in.) touchscreen infotainment system with seven speakers, rear-facing camera, Android™ Auto, Bluetooth® connectivity, AM/FM/SiriusXM® Satellite bands |
||
| Storage | Total: 47.3 L 12.5 gal. Six cup holders: 4.6 L 1.2 gal. Center tray: 1.2 L 0.3 gal. Storage pocket: 1.4 L 0.4 gal. Glove box: 3.8 L 1.0 gal. Under seat: 36.4 L 9.6 gal. |
||
| Seating | Genuine leather 40/60 split three-passenger bench |
