Specifications
Key Specs
| Engine power | 38.8 kW 52 hp |
|---|---|
| Cargo box dimensions | 1143 x 305 x 1320 mm 45 x 12 x 52 in. |
| Cargo box capacity (weight) | 454 kg 1000 lb |
| Towing capacity | 680 kg 1500 lb |
| Front suspension | Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel |
| Rear suspension | Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel |
| Final drive | Park, high, low, neutral, reverse transaxle |
| Four wheel drive | Dash switch actuated four-wheel drive system |
| Fuel capacity | 27.6 L 7.3 U.S. gal. |
Engine
| Type | 4-cycle gas, electronic fuel injection (EFI) |
|---|---|
| Displacement | 812 cc |
| Power | 38.8 kW 52 hp |
| Cooling system | Liquid |
Drivetrain
| Transmission | Continuously Variable Transmission (CVT) with clutch enclosure |
|---|---|
| Final drive | Park, high, low, neutral, reverse transaxle |
| Four wheel drive | Dash switch actuated four-wheel drive system |
| Traction assist | Limited slip front differential, Positive locking, switch actuated rear differential lock |
| Descent control | Yes |
Suspension
| Front | Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel |
|---|---|
| Rear | Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel |
Brakes
| Type | Front/rear hydraulic disc with twin piston front calipers |
|---|---|
| Park brake | Park in-transmission, Optional factory-installed secondary foot operated with hand release |
Tires / Wheels
| Front | 27×9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel or alloy wheels 27×9-R14 Predator Heavy-Duty all-terrain radials on steel or alloy wheels |
|---|---|
| Rear | 27×11-R14 Maxxis Bighorn 2.0 extreme terrain radials on steel or alloy wheels 27×11-R14 Predator Heavy-Duty all-terrain radials on steel or alloy wheels |
Dimensions / Capacities
| Wheelbase | 2896 mm 114 in. |
|---|---|
| Weight | With fuel and fluids: 953 kg 2101 lb |
| Length | 3911 mm 154 in. |
| Width | 1574 mm 62.0 in. |
| Height | 1903 mm 74.9 in. |
| Tread centers | 1305 mm 51.4 in. |
| Ground clearance | 280 mm 11.0 in. |
| Fuel capacity | 27.6 L 7.3 U.S. gal. |
| Cargo box dimensions | 1143 x 305 x 1320 mm 45 x 12 x 52 in. |
| Cargo box capacity (weight) | 454 kg 1000 lb |
| Payload capacity | 592 kg 1305 lb |
| Towing capacity | 680 kg 1500 lb |
| Hitch | Standard receiver: 5.1 cm 2 in. |
Features
| Color | Green and yellow, TrueTimber® KANATI® camo, olive and black |
|---|---|
| Power steering | Yes |
| Battery / Alternator / Power port | Battery: 12 V 480 CCA Alternator: 85 amp DC outlet: 12 V |
| Instrumentation | Digital display (gear position, system diagnostic light, speed, rpm, 4WD indicator, rear differential indicator, fuel level, coolant temperature, hour meter, miles, and service interval warning light) |
| Storage | Total: 45.1 L 11.9 gal. Front console tray with two cup holders: .9 L 2 gal. Rear console tray with two cup holders: 1.0 L .3 gal. Glove box: 7.6 L 2.0 gal. Under rear seat: 29.8 L 7.9 gal. Under hood: 5.8 L 1.5 gal. |
| Seating | Black vinyl front and rear bench (four-passenger) |
