Key Specs
| Belts-other – width | 17.8 cm 7 in. |
||
|---|---|---|---|
| Density control | Hydraulic | ||
| Bale size indication | Electronic display on monitor | ||
| Regular pickup – Bars | Four | ||
| Regular pickup – Number of teeth | 72 | ||
| Regular pickup – Tooth spacing | 6 cm 2.6 in. |
||
| MegaWide Plus pickup – Number of regular teeth | 96 | ||
| MegaWide Plus pickup – Number of mega teeth | 16 | ||
| High-capacity pickup – Number of middle teeth | 120 | ||
| High-capacity pickup – Number of mega teeth | Eight |
Bale
| Size | Diameter 89 – 152 cm 35 – 60 in. Width 117 cm 46 in. 1.2 x 1.5 m 4 x 5 ft |
||
|---|---|---|---|
| Weight | Full-size bale in dry crop 449 kg 1,100 lb Max. allowable for silage bale 794 kg 1,750 lb |
Baler
| Base weight | |||
|---|---|---|---|
| Weight | Shipping dry – 1,733 kg 3,820 lb Shipping silage – 2,708 kg 5,972 lb Shipping precutter – 3,691 kg 8,138 lb |
||
| Length | Gate closed 361 cm 142 in. Gate open 455 cm 179 in. |
||
| Height | Gate closed 260 cm 102 in. Gate open 325 cm 128 in. |
||
| Width | With standard tires 226 cm 89 in. With opt. tires (Hi-Flotation) 244 cm 96 in. |
Bale forming
| Forming chamber | |||
|---|---|---|---|
| Belts-other | Number Six Width 17.8 cm 7 in. Texture Diamond Tread friction surface belts DiamondTough, triple-weave, single-ply belts |
||
| Enclosed percent of bale surface | |||
| Belt splices | |||
| Density control | Hydraulic | ||
| Bale size indication | Electronic display on monitor | ||
| Bale Shape |
Regular pickup
| Type | |||
|---|---|---|---|
| Width | Inside 117 cm 46 in. Flare 141 cm 56 in. |
||
| Drive | |||
| Bars | Four | ||
| Number of teeth | 72 | ||
| Tooth spacing | 6 cm 2.6 in. |
||
| Lift control | Adjustable height control | ||
| Gauge wheels | Semi-pneumatic | ||
| Stripper diameter | 25.4 cm 10 in. |
MegaWide Plus pickup
| Type | |||
|---|---|---|---|
| Width | Inside 155 cm 61 in. Flare 180 cm 71 in. |
||
| Drive | |||
| Bars | |||
| Number of regular teeth | 96 | ||
| Number of mega teeth | 16 | ||
| Tooth spacing | |||
| Lift control | |||
| Gauge wheels | Semi-pneumatic | ||
| Stripper diameter |
High-capacity pickup
| Type | MegaWide High Capacity and Cutting (HC | ||
|---|---|---|---|
| Width | Inside 196 cm 77 in. Flare 221 cm 87 in. |
||
| Drive | |||
| Bars | |||
| Number of middle teeth | 120 | ||
| Number of mega teeth | Eight | ||
| Tooth spacing | |||
| Lift control | |||
| Gauge wheels | Semi-pneumatic | ||
| Stripper diameter | 25.4 cm 10 in. |
Wrapping system
| Control | Automatic to preset to bale size | ||
|---|---|---|---|
| Type | Standard Electric |
||
| Twine arms | Two | ||
| Twine ball capacity | Four |
Monitor
| Monitor console for tractor | |||
|---|---|---|---|
| Gate closed | Symbol on monitor | ||
| Bale forming | BaleTrak Pro | ||
| Bale size | Digital | ||
| Near full bale | Audible, adjustable alert | ||
| Full bale | Audible, adjustable alert | ||
| Twine arm position Indicator | Mechanical | ||
| Auto wrap | Activates when bale reaches preset size | ||
| Oversize bale | Yes, audible and mechanical alerts |
Tire size
| Standard | Dry – 11 L – 14 Silage – high-flotation 14 L – 16.4, 8 PR |
||
|---|---|---|---|
| Optional | Dry – high-flotation 14 L – 16.1, 8 PR With MegaWide Plus or MegaWide HC |
Driveline
| Drive protection | Slip clutch | ||
|---|---|---|---|
| PTO speed | 540 rpm MegaWide HC rpm |
||
| Type | Constant-velocity (CV) | ||
| PTO lockback collar on tractor hookup | Yes | ||
| PTO 60-degree free rotation | Yes |
Tractor Requirements
| Minimum PTO | Dry Hay and Silage – 42 kW 55 hp MegaWide HC kW 80 hp 85 hp |
||
|---|---|---|---|
| Hydraulic SCV valves | One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap. Two tractor SCVs are required when baler is equipped with hydraulic twine wrap. Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift. |
Silage baler features
| Starter roll scraper | |||
|---|---|---|---|
| Powered scraping auger | |||
| Spirals on gate roll | |||
| Pre-cutter/slicer |
Additional information
| Maintenance chains | |||
|---|---|---|---|
| Date collected | 14-February-2018 |
